All product items
37
| Product ID | Name | Cross-section | Fire class | Package | In stock |
|---|---|---|---|---|---|
| 00001 | N2XH-O | 1x95 RM | B2ca | Drum | To order |
| 00002 | N2XH-O | 1x120 RM | B2ca | Drum | To order |
| 00003 | N2XH-O | 1x150 RM | B2ca | Drum | To order |
| 00003 | N2XH-O | 1x185 RM | B2ca | Drum | To order |
| 00004 | N2XH-O | 1x240 RM | B2ca | Drum | To order |
| 00005 | N2XH-O | 1x300 RM | B2ca | Drum | To order |
| 00006 | N2XH-J | 3x1,5 RE | B2ca | Drum | In stock |
| 00007 | N2XH-J | 3x2,5 RE | B2ca | Drum | In stock |
| 00008 | N2XH-J | 3x4 RE | B2ca | Drum | In stock |
| 00009 | N2XH-J | 3x6 RE | B2ca | Drum | To order |
| 00010 | N2XH-J | 3x10 RE | B2ca | Drum | To order |
| 00011 | N2XH-J | 3x16 RE | B2ca | Drum | To order |
| 00012 | N2XH-J | 4x1,5 RE | B2ca | Drum | In stock |
| 00013 | N2XH-J | 4x2,5 RE | B2ca | Drum | To order |
| 00014 | N2XH-J | 4x4 RE | B2ca | Drum | To order |
| 00015 | N2XH-J | 4x6 RE | B2ca | Drum | To order |
| 00016 | N2XH-J | 4x10 RE | B2ca | Drum | To order |
| 00017 | N2XH-J | 4x16 RE | B2ca | Drum | To order |
| 00018 | N2XH-J | 4x25 RM | B2ca | Drum | To order |
| 00019 | N2XH-J | 4x35 RM | B2ca | Drum | To order |
| 00020 | N2XH-J | 4x50 RM | B2ca | Drum | To order |
| 00021 | N2XH-J | 4x70 RM | B2ca | Drum | To order |
| 00022 | N2XH-J | 4x95 RM | B2ca | Drum | To order |
| 00023 | N2XH-J | 4x120 RM | B2ca | Drum | To order |
| 00024 | N2XH-J | 4x150 RM | B2ca | Drum | To order |
| 00025 | N2XH-J | 4x185 RM | B2ca | Drum | To order |
| 00026 | N2XH-J | 4x240 RM | B2ca | Drum | To order |
| 00027 | N2XH-J | 5x1,5 RE | B2ca | Drum | In stock |
| 00028 | N2XH-J | 5x2,5 RE | B2ca | Drum | In stock |
| 00029 | N2XH-J | 5x4 RE | B2ca | Drum | In stock |
| 00030 | N2XH-J | 5x6 RE | B2ca | Drum | In stock |
| 00031 | N2XH-J | 5x10 RE | B2ca | Drum | To order |
| 00032 | N2XH-J | 5x16 RE | B2ca | Drum | To order |
| 00033 | N2XH-J | 5x25 RM | B2ca | Drum | To order |
| 00034 | N2XH-J | 5x35 RM | B2ca | Drum | To order |
| 00035 | N2XH-J | 5x50 RM | B2ca | Drum | To order |
| 00036 | N2XH-J | 5x70 RM | B2ca | Drum | To order |
Similar products
-0,6-1kV.jpg)
Technical data
| Customs Tariff Number (code number): | 85444999 |
| Standard: | PN-HD 604 S1:2002 |
| Conductor material: | Copper |
| Insulation: | cross-linked polyethylene |
| Flame-retardant: | IEC 60332-1 |
| Sheathing material: | special HF |
| Filling compound: | special HF rubber |
| UV-resistant: | No |
| For outdoor use: | Yes |
| Max. temperature at conductor, °C: | Max 90°C |
| Laying temperature, °C: | Min -5°C |
| Operating temperature, °C: | -40 to +70°C |
| Core identification: | Colours acc. HD 308 S2 |
| Colour of outer sheath: | Black |
| Unit of measurement: | Metre |
Application
Halogen-free power supply cables for installations in facilities where human life and property must be protected against fire (hotels, hospitals, schools, airports, underground and train stations, industrial installations); cables to be laid in dry and moist rooms, over and in plasterwork, in brick walls and directly in concrete; only permanent installation possible; in outdoor or underground installations cables must be laid in cable ducts or tubes.
