All product items
8
| Product ID | Name | Cross-section | Fire class | Package | In stock |
|---|---|---|---|---|---|
| 00001 | YDYp-O | 2x1,0 RE | Eca | Coil | In stock |
| 00002 | YDYp-O | 2x1,5 RE | Eca | Coil | In stock |
| 00003 | YDYp-O | 2x2,5 RE | Eca | Coil | In stock |
| 00004 | YDYp-O | 3x1,0 RE | Eca | Coil | In stock |
| 00005 | YDYp-J | 3x1,5 RE | Eca | Coil | In stock |
| 00006 | YDYp-J | 3x2,5 RE | Eca | Coil | In stock |
| 00007 | YDYp-J | 3x4 RE | Eca | Coil | In stock |
| 00008 | YDYp-J | 4x1,5 RE | Eca | Coil | In stock |
Similar products
ym-o-(N)ym-j-500v.jpg)
Technical data
| Customs Tariff Number (code number): | 85444995 |
| Standard: | PN-EP-66:2012 |
| Conductor material: | Copper |
| Insulation: | PVC |
| Self-extinguishing: | IEC 60332-1-2 |
| Sheathing material: | PVC |
| UV-resistant: | No |
| For outdoor use: | No |
| Max. temperature at conductor, °C: | Max 70°C |
| Laying temperature, °C: | Min -5°C |
| Operating temperature, °C: | -40 to +70°C |
| Core identification: | Colours acc. HD 308 |
| Colour of outer sheath: | Balta |
| Unit of measurement: | Metrs |
Application
Cables are designed for fixed installation, indoors, in the air, in and under plaster. Installation of the product should only be carried out by personnel trained and qualified for electrical works. The product is designed according to recognized standards. Applicable rules of installation must be applied at all times.
Technical documents
| YDYp 300/500V | Data sheet | Download |
| YDYp 300/500V | Declaration of conformity " CE" | Download |
| YDYp 300/500V | Declaration of performace " DOP" | Download |
